TSUBAKI
Chain No. |
ANSI
No |
Pitch |
Pin |
Transverse
Pitch
C |
Approx
Weight
kg/m {kgf} |
Approx
Weight
kg/m |
Form
Pin
Head to C.
L1 |
Form
Pin
End to C.
L2 |
| RS50-5 |
50-5 |
15.875 |
46.5 |
48.3 |
18.1 |
157 {16,000} |
5.14 |
| RS50-4 |
50-4 |
15.875 |
37.45 |
39.25 |
18.1 |
126 {12,800} |
4.11 |
| RS50-3 |
50-3 |
15.875 |
28.4 |
60.2 |
18.1 |
94.1 {9,600} |
3.09 |
| RS50-2 |
50-2 |
15.875 |
19.35 |
21.15 |
18.1 |
62.8 {6,500} |
2.07 |
| RS60-6 |
60-6 |
19.05 |
69.9 |
72.5 |
22.8 |
265 {17,000} |
9.05 |
| RS60-5 |
60-5 |
19.05 |
58.5 |
61.0 |
22.8 |
221 {22,500} |
7.57 |
| RS60-4 |
60-4 |
19.05 |
47.05 |
49.55 |
22.8 |
177 {18,000} |
6.04 |
| RS60-3 |
60-3 |
19.05 |
36.65 |
38.15 |
22.8 |
132 {13,500} |
4.54 |
| RS60-2 |
60-2 |
19.05 |
24.25 |
26.75 |
22.8 |
88.3 {9,000} |
3.04 |
| RS80-6 |
80-6 |
25.40 |
89.6 |
92.5 |
29.3 |
471 {48,000} |
15.73 |
| RS80-5 |
80-5 |
25.40 |
74.95 |
77.95 |
29.3 |
392 {40,000} |
13.11 |
| RS80-4 |
80-4 |
25.40 |
60.25 |
63.25 |
29.3 |
314 {32,000} |
10.50 |
| RS80-3 |
80-3 |
25.40 |
45.6 |
48.5 |
29.3 |
235 {24,000} |
7.89 |
| RS80-2 |
80-2 |
25.40 |
30.9 |
33.9 |
29.3 |
157 {16,000} |
5.27 |
| RS100-6 |
100-6 |
31.75 |
109.45 |
112.55 |
35.8 |
706 {72,000} |
23.48 |
| RS100-5 |
100-5 |
31.75 |
91.5 |
94.6 |
35.8 |
588 {60,000} |
19.53 |
| RS100-4 |
100-4 |
31.75 |
73.55 |
76.65 |
35.8 |
471 {48,000} |
15,70 |
| RS100-3 |
100-3 |
31.75 |
55.65 |
58.75 |
35.8 |
353 {36,000} |
11.77 |
| RS100-2 |
100-2 |
31.75 |
37.7 |
40.8 |
35.8 |
235 {24,000} |
7.85 |
| RS120-6 |
120-6 |
38.10 |
138.55 |
142.55 |
45.4 |
1000 {102,000} |
34.96 |
| RS120-5 |
120-5 |
38.10 |
115.85 |
119.85 |
45.4 |
834 {85,000} |
29.16 |
| RS120-4 |
120-4 |
38.10 |
93.1 |
97.1 |
45.4 |
667 {68,000} |
23.36 |
| RS120-3 |
120-3 |
38.10 |
70.4 |
74.4 |
45.4 |
500 {51,000} |
17.53 |
| RS120-2 |
120-2 |
38.10 |
47.6 |
51.6 |
45.4 |
333 {34,000} |
11.70 |
| RS140-6 |
140-6 |
44.45 |
149.3 |
154.2 |
48.9 |
1290 {132,000} |
44.30 |
| RS140-5 |
140-5 |
44.45 |
124.8 |
129.6 |
48.9 |
1080 {110,000} |
36.97 |
| RS140-4 |
140-4 |
44.45 |
100.3 |
105.2 |
48.9 |
863 {88,000} |
28.52 |
| RS140-3 |
140-3 |
44.45 |
75.85 |
80.75 |
48.9 |
647 {66,000} |
22.20 |
| RS140-2 |
140-2 |
44.45 |
51.35 |
56.15 |
48.9 |
431 {44000} |
14.83 |
| RS160-6 |
160-6 |
50.80 |
178.3 |
183.3 |
58.5 |
1680 {171.000} |
59.93 |
| RS160-5 |
160-5 |
50.80 |
149.05 |
153.95 |
58.5 |
1400 {142,500} |
49.89 |
| RS160-4 |
160-4 |
50.80 |
119.75 |
124.65 |
58.5 |
1120 {114,000} |
40.06 |
| RS160-3 |
160-3 |
50.80 |
90.45 |
94.45 |
58.5 |
838 {85,500} |
30.02 |
| RS160-2 |
160-2 |
50.80 |
61.15 |
66.15 |
58.5 |
559 {57,000} |
20.04 |
| RS180-6 |
RS180-6 |
57.15 |
200.55 |
207.35 |
65.8 |
2180 {226,200} |
76.27 |
| RS180-5 |
180-5 |
57.15 |
167.6 |
174.4 |
65.8 |
1850 {188,500} |
63.59 |
| RS180-4 |
180-4 |
57.15 |
134.65 |
141.45 |
65.8 |
1480 {150,800} |
50.90 |
| RS180-3 |
180-3 |
57.15 |
101.7 |
108.5 |
65.8 |
1110 {113.100} |
38.22 |
| RS180-2 |
180-2 |
57.15 |
68.75 |
75.35 |
65.8 |
739 {75,400} |
26.52 |
| RS200-6 |
200-6 |
63.50 |
218.25 |
224.05 |
71.6 |
2820 {288,000} |
97.59 |
| RS200-5 |
200-5 |
63.50 |
182.4 |
188.2 |
71.6 |
2350 {240,000} |
81.32 |
| RS200-4 |
200-4 |
63.50 |
146.6 |
152.3 |
71.6 |
1880 {192.000} |
65.16 |
| RS200-3 |
200-3 |
63.50 |
110.75 |
116.45 |
71.6 |
1410 {144,000} |
49.02 |
| RS200-2 |
200-2 |
63.50 |
74.85 |
80.65 |
71.6 |
941 {96,000} |
65.16 |
| RS240-6 |
240-6 |
76.20 |
267.7 |
275.1 |
87.8 |
4120 {420,000} |
142.10 |
| RS240-5 |
240-5 |
76.20 |
223.75 |
231.25 |
87.8 |
3430 {350,000} |
118.60 |
| RS240-4 |
240-4 |
76.20 |
179.8 |
187.3 |
87.8 |
2750 {280,000} |
95.10 |
| RS240-3 |
240-3 |
76.20 |
135.85 |
143.15 |
87.8 |
2060 {210,000] |
71.60 |
| RS240-2 |
240-2 |
76.20 |
91.9 |
99.4 |
87.8 |
1370 {140,000} |
48.10 |
|
